Workpiece: Valve, pump, auto parts; ring, flange, shell parts
Function: Turning, grooving, drilling, tapping, reaming
PACKING, FIXING & DELIVERY:
CUSTOMERS' VISITING:
FAQ
1. MOQ
1 set
2. DELIVERY TIME
It depends on the machine and model you choose. Mostly 2 months - 4months. All machines are 100% new and not used.
3. PAYMENT TERM
T/T 30% down payment when order, 70% balance payment before shipment.
4. WARRANTY PERIOD
13 months from the date of B/L, during the warranty period, daily damage parts will be supplied freely, the after sale service will be done by dealers . After warranty period, the spare parts will be supplied at factory price.
Function: Turning, grooving, drilling, tapping, reaming
Main Technical Parameters:
| Specification | Model Unit | C5116 |
| Max turning diameter | mm | 1600 |
| Table diameter | mm | 1400 |
| Max height of workpiece | mm | 1200 |
| Max weight of the workpiece | t | 5 |
| Max torque of table | KN.m | |
| Speed range of Table (16steps) | r/min | 5-160 |
| Main motor power | KW | 22 |
| Machine dimension | mm | 2830x2670x3010 |
| Machine weight | t | 12 |
Standard Accessories:
| Name | Q'ty |
| Chuck jaw | 4 sets |
| Tool holder | 1 pc |
| Tool shank | 1 pc |
| Spanner for tool post | 1 pc |
| Spanner for chuck | 1 pc |
| Ring spanner 36 | 1 pc |
| Oil gun | 1 pc |
| Anchor bolt | 7 sets |
| Machine pad | 8 pcs |
PACKING, FIXING & DELIVERY:
CUSTOMERS' VISITING:
FAQ
1. MOQ
1 set
2. DELIVERY TIME
It depends on the machine and model you choose. Mostly 2 months - 4months. All machines are 100% new and not used.
3. PAYMENT TERM
T/T 30% down payment when order, 70% balance payment before shipment.
4. WARRANTY PERIOD
13 months from the date of B/L, during the warranty period, daily damage parts will be supplied freely, the after sale service will be done by dealers . After warranty period, the spare parts will be supplied at factory price.
